ANENJI 11000W 48V WIFI User Manual
11KW 48V Hybrid Off-Grid+On-Grid Solar Inverter introduction
| MODEL | ANJ-HHS-11KW-48V-WIFI |
| Capacity | 11KVA/11KW |
| Maximum py Input Power | 11KW |
| Parallel Capability | NO |
| Lithium Battery Activation | YES ( By PV or Utility) |
| Lithium Battery Communication | YES(RS485) |
| INPUT | |
| Nominal Voltage | 230VAC |
| Acceptable Voltage Range | 170-280VAC(For personal Computer):90-280VAC(For Home Appliances) |
| Frequency | 50/60 Hz (Auto sensing) |
| OUTPUT | |
| Nominal Voltage | 220/230/240VAC |
| Surge Power | 22000VA |
| Frequency | 50/60 Hz |
| Wavefomm | Pure Sine wave |
| Transfer Time | 10ms(For personal Computer):20ms(For Home Appliances) |
| Peak Efficiency | 94% |
| Overload Protection | 5s@>=140%load; 10s@110%~140% load |
| Admissible Power Factor | 0.6-1 (inductive or capacitive) |
| Grid-tie Operation | NO |
| BATTERY | |
| Battery Voltage | 48VDC |
| Maximum Discharge Curent | 220A |
| Floating Charge Voltage | 54VDC |
| OverCharge Protection | 63VDC |
| Charging Methad | CC/CV |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger TYPE | MPPT |
| Max.PV Array Power | 5500W*2 |
| Max, PV Array Open Circuit Voltage | 500VDC |
| PV Array MPPT Voltage Range | 60VDC~500VDC |
| Max, Solar input Current | 27A*2 |
| Max, Solar Charge Current | 160A |
| Max. AC Charge Current | 120A |
| Max, Charge Current | 160A |
| PHYSICAL | |
| Dimensions, D x w x H(mm) | 540*415*122 |
| Net Weight (Kgs) | 15 |
| Communication Interface | RS485/DRY CONTACT |
| LCD | YES |
| ENVIRONMENT | |
| Operating Temperature Range | -10°C to 50°C |
| Storage temperature | -15°C~ 60°C |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
Feed into the grid
lf solar energy is sufcient to all connected loads and charge battery, the solar energy could feedback to the grid.
If solar energy is not sufcient to power all connected loads,utility energy will supply power to the loads at the same time.
Monitor andcontrol via smartes App
You can check the status of your device using wifi
Low-noise operation
Adopting noise reduction technology, it is quiet and does not disturb sleep.
