EU and Chinese warehouses have stock available;
Click to download ANENJI 2.5W 12V Solar Inverter User Manual
Click to Buy ANENJI 12V 100AH LiFePO4 Battery
| MODEL | ANJ-2500W-12V-WIFI |
| Capacity | 2.5KVA/2.5KW |
| Parallel Capability | NO |
| Lithium Battery activation | YES (By PV or Utility) |
| Lithium Battery communication | YES(RS485) |
| WIFI | Optional |
| INPUT | |
| Nominal Voltage | 230VAC |
| Acceptable Voltage Range | 170-280VAC(For personal Computer);90-280vac(For Home Appliances) |
| Frequency | 50/60 Hz(Auto sensing) |
| OUTPUT | |
| Nominal Voltage | 220/230VAC+5% |
| Surge Power | 5000VA |
| Frequency | 50/60Hz |
| Waveform | Pure Sine wave |
| Transfer Time | 10ms(For personal Computer);20ms(For Home Appliances) |
| Peak Efficiency(PV to INV) | 96% |
| Peak Efficiency(Battery to INV) | 93% |
| Overload Protection | 5s@>=140% load; 10s@110%~140% load |
| Crest Factor | 3:1 |
| Admissible Power Factor | 0.6~1 (inductive or capacitive) |
| BATTERY | |
| Battery Voltage | 12VDC |
| Floating Charge Voltage | 13.5VDC |
| OverCharge Protection | 16VDC |
| Charging Method | CC/CV |
| SOLAR CHARGER & AC CHARGER | |
| Solar Charger Type | MPPT |
| Max.PV Array Power | 3000W |
| Max.PV Array Open Circuit Voltage | 500Vdc |
| PV Array MPPT Voltage Range | 50Vdc-500Vdc |
| Max.Solar Input Current | 15A |
| Max.Solar Charge Current | 120A |
| Max.AC Charge Current | 120A |
| Max.Charge Current (PV+AC) | 120A |
| PHYSICAI | |
| Dimensions,D x W x H(mm) | 368x327.4x120.5 |
| Package Dimensions,D x W x H(mm) | 478x408x195 |
| Net Weight(Kg) | 6 |
| Gross weight(Kgs) | 7 |
| Communication Interface | RS232+RS485 |
| ENVIRONMENT | |
| Operating Temperature Range | -10°Cto 55°C |
| Storage Temperature | -15°C~60°C |
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| Ingress Protection | IP21 |
